The Multi-award winning performance range presents the performance audio analogue interconnect.
Performance Audio utilises design concepts from the high end Reference range to optimise audio performance when connecting your CD player, DAC or Tuner to your amplifier or receiver. These include quasi-balanced geometry, low capacitance dielectric materials and 24k gold plated RCA plugs.
QED offers a lifetime guarantee on this cable
99.999% OXYGEN FREE COPPER CONDUCTORSProvide a low resistance pathway for the audio signal
LOW DENSITY POLYETHYLENE DIELECTRICbecause of its low dielectric constant this material has been used to cut down on the amount of audio signal energy lost due to cable capacitance
ERGONOMICALLY SCULPTURED ZINC PLATED ALLOY BARRELProvides ease of installation and a stunning finish | 24K GOLD PLATED PHONO PLUGSBecause gold does not tarnish it provides a lasting low resistance contact
ELECTROSTATIC SCREENProvides immunity from external high voltage noise signals. Only connected at the source equipment end hence the directionality arrows on the cable jacket.
QUASI-BALANCED GEOMETRYSignal and return conductors are twisted together to give a level of common mode noise rejection above that of conventional unbalanced cables |
Product specifications
Type: | Performance Audio Graphite |
Colour: | Black, Silver |
Length: | 0.6m, 1m, 3m or 5m |
Connector Type: | 2x RCA male > 2x RCA male |
Connector Material: | 24k Gold plated QED 6 leaf RCA plugs |
Conductor Material: | 99.999% Oxygen free copper |
Insulation: | Shielded for enhanced signal protection. |
Loop resistance: | 0.160 Ω/m |
Dissipation Factor: | 0.0012 |
Capacitance: | 115pF/m |
Inductance: | 0.74uH/m |
