The REDCATT 8FR is a 8.0" 4 ohm full-range woofer for efficient single-point loudspeaker designs, combining a bamboo-fiber reinforced paper cone, ferrite motor, and response extension up to 15 kHz.
Â
Highlights of the REDCATT 8FR
- 8.0" full-range driver for single-point Hi-Fi applications
- Lightweight paper cone reinforced with bamboo fibers
- Working range extends up to 15 kHz
- 93 dB sensitivity with 60 W continuous power handling
- Ferrite magnet system with copper shorting cup for improved mid-high behavior
Â
Product details REDCATT 8FR
REDCATT 8FR 8.0" Full-Range Woofer 4 Ohm
Â
The REDCATT 8FR is designed for Hi-Fi applications where a single-point audio source is desired. As a full-range woofer, it uses a lightweight yet strong paper pulp cone reinforced with bamboo fibers, helping it cover a wide operating range while maintaining a clean, modern appearance for exposed-driver loudspeaker builds.
Â
Its whizzer-style cone and bullet-style phase plug help extend the working range up to 15 kHz and support smooth sound reproduction both on and off axis. This makes the 8FR a strong choice for builders looking for efficient woofers that can deliver wideband performance without a conventional multi-way layout.
Â
The ferrite magnetic circuit is engineered to provide a robust B-field across the driver’s working range, while the copper shorting cup improves behavior in the mid-high region. Key specifications include 4 ohm rated impedance, 93 dB sensitivity, 30 W AES power, 60 W continuous power, and 120 W peak power handling.
Â
For enclosure design, the 8FR is suited to vented speaker systems. Recommended bass reflex alignments include 20 liters tuned to 61 Hz for strong mid-bass output, 24 liters tuned to 56 Hz for a balanced general-purpose response, or 24 liters tuned to 50 Hz for deeper low-frequency extension with high-pass filter protection.
