The HY WOXG/WOXMG Series is a compact and robust glass passivated bridge rectifier, engineered for reliable performance in demanding electronic applications. With a reverse voltage rating ranging from 50 to 1000 volts and a continuous forward current of 1.5 amperes, this bridge rectifier is an ideal choice for printed circuit board integration where durability and cost-effectiveness are paramount.
Highlights of the HY WOXG/WOXMG Series
- Surge overload capacity up to 40 amperes peak
- Wide reverse voltage range: 50 to 1000 volts
- 1.5 ampere continuous forward current for steady operation
- Reliable molded plastic construction for cost-effective, long-lasting use
Product details HY WOXG/WOXMG Series
HY WOXG/WOXMG Series Glass Passivated Bridge Rectifier 1.5A 50-1000V
This series of glass passivated bridge rectifiers is specifically designed for use in printed circuit board assemblies, offering a compact footprint and flexibility with mounting positions. The molded plastic housing ensures enhanced durability and protection, making the WOXG/WOXMG Series suitable for environments where mechanical stability is crucial and space is at a premium.
Performance is a defining aspect of the HY WOXG/WOXMG Series. The bridge rectifier delivers a maximum average forward rectified current of 1.5 amperes and can withstand non-repetitive surge currents up to 40 amperes. With a low forward voltage drop of just 1.1 V per element at 1.5A peak, it guarantees efficient operation with minimal power loss, which is essential for maintaining system reliability in both resistive and inductive load scenarios.
The WOXG/WOXMG Series is versatile enough for a variety of electronics, power conversion, and audio component projects. Its broad voltage and current ranges make it suitable for integration into power supplies, amplifiers, and DIY electronic kits. For capacitive loads, derating by 20% is recommended, which highlights the device€™s adaptability to different application requirements, including those found in power supply designs and other board-level solutions.
Engineers and hobbyists alike will appreciate the ease of installation offered by the standardized pin spacing and lead dimensions, which streamline assembly in both prototyping and production runs. This makes the HY WOXG/WOXMG Series a valuable component for anyone working with DIY electronics kits, power management projects, or upgrades of existing electromechanical assemblies, ensuring reliable rectification performance and simplified circuit integration.
