DDRC-88A 8xIN, 8xOUT Dirac Live

Name: miniDSP DDRC-88A 8xIN, 8xOUT Dirac Live
Brand: miniDSP
Price: 1299.95 EUR

Show all Home audio

Merk: miniDSP

Compare

€ 1.074,34€ 1.299,95 Out of stock expected on //doc.soundimports.nl/pdf/brands/MiniDSP/DDRC-88A/pdf_minidsp_DDRC-88A_2.pdf

Backorder

8xIN, 8xOUT Dirac Live® correction DSP with Balanced & unbalanced Input & output. Boxed in sturdy 1 RU metal enclosure.... Show more

24h express shipping available
Low international shipping rates
Same day shipping
In-house technical support

Product description

8xIN, 8xOUT Dirac Live® correction DSP with Balanced & unbalanced Input & output. Boxed in sturdy 1 RU metal enclosure.

Highlights

Processor: 32-bit floating-point Analog Devices SHARC DSP
Input/ouput resolution: 24 bits
Analog inputs: 8x balanced RCA / 8x balanced phoenix terminal blocks
Analog ouputs: 8x balanced RCA / 8x balanced phoenix terminal blocks
Internal operating sample rate: 48 kHz
Optional DDRC-88BM plugin for Bass Management + Dirac Live + Active Speaker processing (Crossover/PEQ/Delay)

Product details

DDRC-88A

Note: This product comes with a coupon (€9,50) for one free miniDSP plugin download.

Introducing the miniDSP Dirac Series, powered by Dirac Live®, the world's premier room correction solution. We are delighted to offer you this software and hardware combination, the fruit of many years of experience in sound system tuning and extensive research and development. The DDRC-88A is the big brother of the stereo DDRC platform introduced early 2014. Based on our proven 8x8 DSP board and miniSHARC powerful module, the DDRC-88A combines two successful & proven platforms into a cost effective one rack unit processor. An infrared remote learning feature and the front panel rotary encoder allow for control of the DDRC-88A processor without any need for a connected PC, once the processor is configured and filters loaded.

DDRC-88BM

The DDRC-88A is an upgradable platform thanks to the power of the DDRC-88BM plugin. The software plug-in extends the capabilities of the DDRC-88A multichannel Dirac Live® processor. 100% compatible with all DDRC-88A units in the field, the DDRC-88BM adds comprehensive fine-grained bass management and crossover capabilities. The input signals are low-pass filtered and summed to generate the subwoofer signal; a matrix mixer routes or mixes these channels for the Dirac Live® algorithm, which in turn has its outputs routed or mixed to the output channels, where additional high/low pass and parametric filtering takes place. In addition to improved bass management for conventional home theater signal paths, the DDRC-88BM allows innovative solutions like multi-subwoofer control and combined DRC/active loudspeaker setups. The DDRC-88BM plugin is available at miniDSP.

What's in the box?
